用 smartctl 与 smartd 检查磁盘健康、安排自检并接收告警
S.M.A.R.T. 是 Self-Monitoring, Analysis, and Reporting Technology(自我监测、分析与报告技术)的缩写。许多现代存储设备在内部记录温度、重映射扇区、寻道错误等统计信息,软件可以据此观察设备状况,识别潜在故障并对异常数值发出提醒。
它提供的是额外证据,而不是“磁盘一定不会坏”的保证。出现可疑错误或异常声音时,应先保护重要数据,再决定是否进行耗时自检。本稿根据 ArchWiki 的 S.M.A.R.T. 完整页面翻译整理,原作者为 ArchWiki 社区贡献者。核对版本为 oldid 885611,最后修订于 2026-09-14 14:04;本文核对日期为 2026-10-05。
作者、版本与许可
本修订版标题:用 smartctl 与 smartd 检查磁盘健康、安排自检并接收告警。原始文档:S.M.A.R.T.,ArchWiki 修订 885611,原作页面历史起于 2007 年,来源发布者为 ArchWiki。
原作主要贡献者:依据该固定修订的公开历史记录,列出页面创建者及贡献频次靠前的账户:Tkjacobsen(页面创建者)、Nl6720、Erus Iluvatar、Ichimonji10、Kewl、Gen2ly、Bluewanders、Lahwaacz、Manolo。完整修订列表见 ArchWiki 页面历史。上述账户名依历史记录保留,不推测账户背后的自然人姓名。
本修订版作者:未完纪(中文翻译、整理与明确标出的补充)。本修订版发布者:未完纪。Copyright © 2026 未完纪(中文翻译与新增内容)。原页面未另列个人版权通知;其公开内容注明按 GNU Free Documentation License 1.3 or later 提供。
本修订版按 GNU Free Documentation License 1.3 或任何后续版本发布;没有不变章节、封面文字或封底文字。公众可按该许可证复制、分发和修改本文。完整未修改的许可证文本随文附上。

准备 smartmontools
smartmontools 包含命令行工具 smartctl、监控守护进程 smartd,以及更新硬盘数据库的 update-smart-drivedb。在 Arch Linux 上安装 smartmontools 软件包后,还需要确认每一台目标设备本身提供并启用了 SMART。
下面沿用原文的 /dev/device 作为“替换为实际设备”的说明符;它不是可以直接照抄的目标。原文的 # 表示需要相应管理权限,本稿命令块省略提示符以便阅读。操作前要核对型号、序列号、容量与设备路径,尤其不要把分区、USB 桥接设备和另一块磁盘混淆。
用 smartctl 核对支持与能力
smartctl 用来控制大多数 ATA/SATA、SCSI/SAS 硬盘和固态硬盘提供的 SMART 功能。-i 或 --info 会打印设备信息,包括 SMART 是否可用、是否已启用。
smartctl --info /dev/sda | grep 'SMART support is:'
原文示例输出如下,仅用于说明字段含义,不是本文实测:
SMART support is: Available - device has SMART capability.
SMART support is: Enabled
如果设备支持但尚未启用,可使用:
smartctl --smart=on /dev/device
某些设备需要指定接口类型。例如 --device=ata 告诉 smartctl 按 ATA 设备处理,以免向它发送 SCSI 命令。接口类型必须以实际设备和桥接芯片支持为准,不能把一个示例参数套用到所有 USB 或 NVMe 设备。
选择自检,而不是直接启动最长的测试
先查看设备支持哪些自检,以及各自预计需要多长时间:
smartctl -c /dev/sda
原文给出的能力输出示例中,短测预计 1 分钟、长测 74 分钟、运输测试 2 分钟。这些时间属于示例设备;自己的设备可能完全不同。源页导语写“三种”,随后实际列出以下四种,本稿按列出的四种说明:
- Short:短自检,执行较有可能发现问题的一组检查。
- Extended / Long:扩展或长自检,进行完整磁盘表面检查,不受短测的时间限制。
- Conveyance:运输自检,用于发现设备在运输过程中可能发生的损伤。
- Selective:选择性自检,只检查指定的 LBA 范围;具体语法参见 smartctl(8) 的
-t部分。
对应的原文命令为:
smartctl -t short /dev/device
smartctl -t long /dev/device
smartctl -t conveyance /dev/device
smartctl -t select,123+345 /dev/device
这些是不同选择,不是要求依次全部运行。最后一行保留原文的选择性 LBA 示例,实际范围必须另行核对。原文把这些自检描述为对用户数据安全,即并非擦除类测试;这不能扩展为“对疑似损坏设备零风险”。测试会占用时间和设备资源,故障盘应先处理数据保护和业务窗口。
读取健康状态、自检日志和完整信息
-H 显示总体健康状态:
smartctl -H /dev/device
原文引用手册警告:如果设备报告健康失败,可能已经发生故障,也可能在预测短期内故障,应尽快把数据转移到安全位置。原文提到的“未来 24 小时”是设备健康报告的警告语义,不是可以等待 24 小时的安全承诺。反过来,显示通过也不能排除突然故障。
再查看最近自检结果,以及更多属性和日志:
smartctl -l selftest /dev/device
smartctl -x /dev/device
属性编号、原始值单位和含义会随厂商、设备型号及接口变化,不能仅凭一项数字为所有硬盘设定相同结论。应结合错误日志、历史趋势、设备文档与实际故障表现判断。
汇总多块磁盘属性:保留原文脚本,也保留它的限制
原页提供一个 Bash 脚本,把扫描出的设备属性按名称汇总为表格,并对这一节挂有“长脚本应在其他位置维护”的编辑提示。为完整保留原文,这里列出该示例;它不是经过本稿验证的通用磁盘报表工具。
#!/bin/bash
function drives_csv {
declare -A drive_values
for d in `smartctl --scan -d scsi | cut -d' ' -f1`; do
drive_values["-Drive-----------------"]="${drive_values[-Drive-----------------]},$d"
for l in `smartctl -A $d | grep ATTRIBUTE_NAME -A30 | grep -v ATTRIBUTE_NAME | column -H1,3,4,5,6,7,8,9,11,12,13,14,15 -t -o, | sed 's/ //g'`; do
key=`echo $l | cut -d',' -f1`
value=`echo $l | cut -d',' -f2`
existing=${drive_values["$key"]}
drive_values["${key}"]="${existing},${value}"
done
done
for key in "${!drive_values[@]}"; do
echo "${key}${drive_values[$key]}"
done | sort
}
drives_csv | column -s, -t
静态审核:脚本依赖英文文本标题、固定属性列、grep -A30 和特定 column 选项;不同版本、设备类型或属性数量都可能破坏假设。--scan -d scsi 的扫描范围也不能叫作“所有类型磁盘”。未加引号的 $d、$l 会发生词拆分和通配符展开,属性缺失时,各设备的值还可能错列。把这种结果直接用于自动换盘决策并不可靠。
本稿只按原文整理缩进、删除一条已注释的调试输出,没有宣称修好了这段脚本。更稳妥的工程实现应使用明确设备清单与结构化输出,并为缺失字段保留列位置;那需要单独设计和验证,不能靠更换几个引号就保证正确。
让 smartd 持续监控
smartd 持续监控 SMART 状态并在异常时发出通知。Arch Linux 上的配置文件是 /etc/smartd.conf,通过 smartd.service 管理服务。可以使用 systemd 启动服务、查看状态、设置开机启动并读取日志。其配置语法较密集,下文是原文的速查用途,完整选项仍应参照配置文件注释和 smartd.conf(5)。
明确要监控的设备
扫描可发现的磁盘并监控全部支持的 SMART 项目:
DEVICESCAN -a
这是默认配置形式,-a 也是默认选项,可以省略。如果只想监控两块指定磁盘,应改为逐设备配置:
/dev/sda -a
/dev/sdb -a
USB 备份盘重插或系统重启后,/dev/sdX 名称可能变化。原文因此建议持久化设备路径,并展示了以下 UUID 示例:
/dev/disk/by-uuid/820cdd8a-866a-444d-833c-1edb0f4becac -a
上面的 UUID 只是原文示例,不属于读者设备。原文还指出可能需要 -d removable。编辑补充:UUID 链接往往指向文件系统或分区;配置时应核对它最终对应的设备,并优先根据硬件标识确认整盘路径与 SMART 接口,不能只因路径是“持久的”就认为一定可用。
邮件告警与通知链路
在出现失败或新错误时发送邮件,用 -m 指定接收地址:
DEVICESCAN -m address@domain.com
这并不会自动配置邮件投递。如果需要把邮件发到外部邮箱,必须安装并配置合适的邮件传输/提交组件。源文提及 msmtp、Postfix、dma、sendmail 和 S-nail 等选择;实际组合取决于系统邮件配置。不要在公开的监控脚本中硬编码 SMTP 密码。
-M test 会在 smartd 每次启动时产生测试邮件,适合核对真实投递链路:
DEVICESCAN -m address@domain.com -M test
它是待执行的告警验证方法,不是本稿已发出邮件的记录。邮件可能延迟,因此还可以使用 -M exec 运行本地通知程序:
DEVICESCAN -m address@domain.com -M exec /usr/local/bin/smartdnotify
原文的脚本同时调用邮件命令和终端广播:
#!/bin/sh
echo "$SMARTD_MESSAGE" | mail -s "$SMARTD_FAILTYPE" "$SMARTD_ADDRESS"
wall "$SMARTD_MESSAGE"
审核边界:wall 会向登录用户广播内容,SMART 消息可能包含主机、设备标识或错误细节;只应在接受这一可见范围的系统上使用。脚本由服务触发,应由管理员控制其所有者和写权限,避免让普通用户改写被高权限服务执行的程序。这里没有调用 shell 的 eval;仍需保持变量引用和可信配置。
桌面环境可以用 libnotify 和兼容的通知服务显示弹窗。下面是原文的单用户方案,user 需要替换为实际用户:
#!/bin/sh
systemd-run --machine=user@.host --user notify-send \
"S.M.A.R.T Error ($SMARTD_FAILTYPE)" "$SMARTD_MESSAGE" \
--icon=dialog-warning -u critical
也可以把脚本放到 /usr/share/smartmontools/smartd_warning.d/,向当前登录用户发送桌面通知。原文循环在命令替换与分号之间含有不换行空格;下面将其改成普通 ASCII 空格,其余逻辑保持原样:
#!/bin/sh
for users in $(loginctl list-users --json short | jq -r '.[].user'); do
systemd-run --machine="$users"@.host --user notify-send \
"S.M.A.R.T Error ($SMARTD_FAILTYPE)" "$SMARTD_MESSAGE" \
--icon=dialog-warning -u critical
done
这段脚本还依赖 jq、libnotify 和可用的用户会话。静态阅读不能证明每个登录用户都有可接收通知的图形会话。脚本仍使用按空白分割用户名的循环,应在目标系统核对兼容性。确保自定义脚本具有执行权限,再通过原文给出的配置调用:
DEVICESCAN -m @smartdnotify
脚本的安装路径和调用方式应与所装 smartmontools 的包装脚本约定一致,不能假设别的发行版完全相同。
避免轮询频繁唤醒待机磁盘
SMART 查询可能把处于低功耗状态的机械盘唤醒。要让 smartd 对待机状态有所区分,原文给出:
DEVICESCAN -n standby,15,q
standby 指定低功耗状态检查边界,15 限定跳过检查的次数,q 抑制相应的常规提示。具体支持仍依赖设备。部分 USB/SAT 设备不支持检查电源状态,日志可能出现原文示例:
CHECK POWER MODE: incomplete response, ATA output registers missing
Device: /dev/sdb [SAT], no ATA CHECK POWER STATUS support, ignoring -n Directive
可通过 journalctl -u smartd 检查这类信息。若 -n 无法工作,可以调整 smartd 的检查间隔;默认是 30 分钟。原文在 Arch 的 /etc/conf.d/smartd 中给出 10,800 秒(3 小时)示例。本稿修正了原行缺少注释符号的问题:
# 每 10800 秒检查一次,也就是 3 小时。
SMARTD_ARGS="-i 10800"
原页把英文解释直接接在赋值后面,如果按 shell 环境文件解析,它可能被误解为命令而非注释。这里把解释移到以 # 开头的独立行。检查间隔变长也会延长发现异常的时间,不能把省电和及时告警当成可以同时无限提高的指标。
安排自检和温度告警
以下计划表示每天 02:00–03:00 的检查窗口启动短自检,每周六 03:00–04:00 的窗口启动长自检:
DEVICESCAN -s (S/../.././02|L/../../6/03)
这是 smartd 计划表达式,不是 cron 表达式,也不保证设备支持所有自检类型。应把计划与系统时区、休眠以及业务负载一并核对。
温度选项示例:
DEVICESCAN -W 4,35,40
它在温度变化达到 4°C 或以上时记录日志,达到 35°C 时记录提示,达到 40°C 时记录并发送警告。不同设备的正常工作温度可能不同,不能把这三个数字当成所有磁盘的通用极限。如果某些盘天然较热或较冷,使用逐设备配置代替一条 DEVICESCAN。
原文给出的当前温度查询方法为:
smartctl -A /dev/device | grep Temperature_Celsius
这依赖设备使用该属性名;没有匹配输出不等于没有温度或没有风险。
组合配置示例
把前面选项组合起来,可以得到原文的完整示例:
DEVICESCAN -a -o on -S on -n standby,q -s (S/../.././02|L/../../6/03) -W 4,35,40 -m username-or-email
DEVICESCAN 扫描设备;-a 监控属性;-o on 启用自动离线数据收集;-S on 启用属性自动保存;-n standby,q 在待机时跳过检查并减少日志;-s 安排测试;-W 监控温度;-m 配置邮件。设备不一定支持全部选项,接收人也必须替换并验证。
更新硬盘数据库
update-smart-drivedb 从 smartmontools 的源码仓库下载新的 drivedb.h,用于识别新设备和相应参数;可替换系统的 /usr/share/smartmontools/drivedb.h。原文称它是按设备条目组织的纯文本数据库。未被识别的设备可以向上游提交信息。完整选项见 update-smart-drivedb(8)。
这是会联网并写入系统数据库的维护操作。本稿没有运行它;生产系统应遵循发行版的软件包与信任验证流程,不要从不明位置下载并替换数据库。
其他命令行和图形界面
原文还列出 libatasmart 的 skdump,以及 sysstat 的 iostat -x。后者的 f_await 很高可能提示磁盘响应慢;响应慢本身也可能来自负载、队列或链路,不能单凭这个指标判定硬件故障。
- DisKMonitor:KDE 下观察 SMART 与 MDRaid 健康状况,原文包名为 AUR 的
diskmonitor。 - GNOME Disks:使用 libatasmart 的 GNOME 前端,包名
gnome-disk-utility。 - GSmartControl:smartctl 的图形界面,可读取 SMART 数据并启动测试。
- Plasma Disks:KDE Plasma 的磁盘健康监控组件。
- QDiskInfo:smartctl 前端,提供接近 CrystalDiskInfo 的使用方式,原文标为 AUR 包。
- scrutiny:SMART 监控 Web 界面,原文标为 AUR 包。
这些是源文列出的工具,不代表本文逐个安装验证或对 AUR 构建脚本作了审核。
USB UAS 模式的通信问题
某些情况下,Linux 的 uas 驱动会禁用 SAT 传输,使 smartmontools 或 hdparm 不能正常和后面的 SATA 设备通信。原文指向 smartmontools 的 SAT with UAS Linux 说明:可能的处理涉及回退到 usb-storage,或借助 usb-storage.quirks 调整 NO_ATA_1X 标志。
这会改变驱动和桥接行为,必须针对具体芯片、内核与设备核对。原文明确提醒自行承担风险;本稿不提供未经设备确认的通用内核参数,也没有修改本机 USB 驱动。
历史(History)
原作:S.M.A.R.T.,2007 年起由 ArchWiki 社区协作编写并发布;固定来源修订为 885611(2026-09-14)。页面没有单独列出个人署名,主要修订贡献者及公开历史链接见本文作者信息。
本修订版:用 smartctl 与 smartd 检查磁盘健康、安排自检并接收告警,2026 年;作者:未完纪(中文翻译、编辑及新增内容);发布者:未完纪。修改包括翻译、重排、代码/配置风险注释和原创示意图。
静态审核与来源说明
本文保留了原文从手动检查、属性汇总、守护进程、告警、电源管理到图形工具与 UAS 故障的完整技术范围。所有命令只做静态审核:没有读取真实磁盘、启动自检、安装服务、发送邮件或更改驱动。明确修正的只有配置注释、不换行空格和“三种/四种”的文字不一致;脆弱的属性汇总脚本则保留并标出限制。没有发现硬编码秘密,未发现不等于没有漏洞。
